Line-In to I2S adapter for WLED controllers

(Shipping only to: DE, PL) Description: With this product, a WLED controller for addressable 5V and 12V LED strips can be built (e.g. SK6812, WS2812B, WS2811, WS2815 etc.), on which, for example, open source WLED software from Aircookie can run. An ESP8266 or ESP32 microcontroller board in D1 mini format is also required for this. A suitable housing is also available in our shop. In addition to ESP8266 and ESP32 microcontroller boards, this board can also be used with Lolin's mini boards with new microcontroller types such as ESP32-C3 mini, ESP32-S2 mini and ESP32-S3 mini. However, the WLED software is still highly experimental for these new types of microcontrollers. This WLED controller board can be connected to 12V or 5V voltage source, depending on whether you want to operate 12V or 5V LED strips. No switching using jumpers etc. is necessary. The GPIOs number to be set for the LED control in WLED SW are printed on the back side of this shield for ESP8266 and ESP32 microcontroller boards. For the newer controller types these are as follows: ESP32-C3: DAT is GPIO 6; CLK is GPIO 7; DAT2 is GPIO 2; CLK2 is GPIO 3 ESP32-S2: DAT is GPIO 16; CLK is GPIO 18; DAT2 is GPIO 7; CLK2 is GPIO 9 ESP32-S3: DAT is GPIO 16; CLK is GPIO18; DAT2 is GPIO 12; CLK2 is GPIO 13 A helpful WLED FAQ can be found at: https://wled-faq.github. io/ Interfaces: 5.. 12V power input LED connection (5...12V, GND, data, clock) Second LED connection (Data2, Clock2) Interface for a digital microphone (INMP441, can only be used with ESP32 microcontroller!) Interface for an analog microphone (e.g. MAX4466) or line-in adapter Can also be equipped with a temperature sensor DS18B20 Features: Capacitor SN74AHCT level shifter Multi-voltage DC/DC for microcontroller and level shifter supply from 5..12 V Current capacity 5..12V path: max. 13A Screw terminals: target torque: 0.4 Nm Screw terminals, cable cross section: 0.5 ... 2.5 mm2, rigid or flexible with wire end sleeve Screw terminals, stripping/sleeve length: 6-7 mm / 8 mm Maximum permanent current carrying capacity of the power path of the device (power supply connection to the LED strip connection, each for +V and GND)*: Cable cross section / Maximum permanent current carrying capacity (*): 0.5 mm2 / 3 A 0.75 mm2 / 6 A 1 mm2 / 9 A 1.5 mm2 - 2.5 mm2 / 13 A Scope of delivery: Shield as described, equipped and with a 15A fuse (without microcontroller!) Notes: Information about WLED software (external website): https://kno.wled.ge / WLED software online installer (external website): https://wled-install.github.io/ Mandatory information:WEEE Reg. No.: DE34359026Manufacturer: MyHome-Control von Dr.-Ing. Wladislaw Waag, Wasserburger Landstr. 29, 81825 München, Germany Warnings: This product is intended for use by persons with relevant electrical engineering knowledge and experience. This means that the person must be able to correctly dimension the light chain or lighting system to be set up (including, for example, selection of the power supply, the light chain, cable selection, any necessary safety elements) and to set it up using relevant electrical engineering standards. Incorrect or improper use can be dangerous. This product may only be operated with safety extra-low voltage (SELF) (protection class III). This product is not a toy! It must be kept out of the reach of children and must not be used as a toy. When connecting to the device terminals, please note the permitted cables and cross sections. Please note the technical data, especially the maximum current carrying capacity of the power path. Overloading can lead to the destruction of this product and/or a fire and must be avoided by carefully designing the light chain or lighting system and, if necessary, integrating the safety elements both in normal operation and in the event of a fault. Install and connect this product only when there is no voltage! Make sure the polarity is correct! We assume no liability for property damage or personal injury caused by improper use or failure to observe the hazard warnings. In these cases, the warranty claim also expires! We assume no liability for consequential damage. Protect this product from electrostatic discharge to avoid damage.

(Shipping only to: DE, PL) Description:  With this product you can set up a light chain or lighting system controlled via WLAN. It is based on an ESP32 microcontroller. To set up a string of lights or a lighting system, you will need a power supply unit and one or more 5V LED strips in addition to this product. The following 5V LED types are supported: WS2812B, WS2813, SK6812(RGBW, RGBNW, RGBWW), APA102, WS2801, LPD8806.The controller essentially consists of an ESP32-WROOM-32 (4MB) module, 1000 uF backup capacitor and an SN74AHCT level converter to ensure trouble-free operation of the LEDs. This product is delivered with the following open source software installed: https://github. com/Aircoookie/WLED (SW licenses here) incl. Audio Reactive Usermod Over-The-Air (OTA) update is possible. Wiki for this open source software can be found at: https://kno.wled.ge A helpful WLED FAQ can be found at: https://wled-faq.github.io/ Usage information about the product: HERE Attention: Although this controller has an analog input for line-in adapter / analog microphone, this is NOT recommended. For Sound Reactive WLED we only recommend a digital microphone (available as an option) or line-in to I2S adapter (also available in the shop). Scope of delivery: WLED controller in a housing (with or without digital microphone depending on the option selected), flashed and tested, so "ready-to-use" Usage information in printed form Technical data: Supply voltage: 5 V +/- 0.1 V Ambient temperature operation: +5 °C … +35 °C WiFi standard: IEEE 802.11 b/g/n, 2.4 GHz Dimensions with housing 97x49x31 mm Maximum permanent current carrying capacity power path (+5V, GND): up to 13 A (depending on cable cross section and environment) Average power consumption in power on state (without load path): 0.50 W Average power consumption in power off (networked standby mode): 0.45 W Average power consumption in AP mode (configuration mode): 0.5 W Current consumption, peak (without load): 800 mA Efficiency at full load: 94% Power loss at full load: 4 W Ambient temperature storage/transport: -20 °C … 60 °C Screw terminals: Target torque: 0.4 Nm Screw terminals, cable cross section: 0.5 ... 2.5 mm2, rigid or flexible with wire end sleeve Screw terminals, stripping/sleeve length: 6-7 mm / 8 mm Protection rating with housing: IP20 Antenna: integrated circuit board antenna 3.7 dBi Weight with case: 62 g The device is not intended for operation in an idle state. Maximum permanent current carrying capacity of the power path of the device (power supply connection to the LED strip connection, each for +5V and GND)*: Cable cross section / maximum permanent current carrying capacity (maximum output power)(*): 0.5 mm2 / 3 A (15 W) 0.75 mm2 / 6 A (30 W) 1 mm2 / 9 A (45 W) 1.5 mm2 - 2.5 mm2 / 13 A (65 W) *This information alone may not be used to dimension the cables. To do this, other conditions such as cable type, type of installation, cable routing, cable length, etc. must be taken into account. Mandatory information:WEEE Reg. No.: DE34359026 Hazard notes: This product is intended for use by persons with relevant electrical engineering knowledge and experience. This means that the person must be able to correctly dimension the light chain or lighting system to be set up (including, for example, selection of the power supply, the light chain, cable selection, any necessary safety elements) and to set it up using relevant electrical engineering standards. Incorrect or improper use can be dangerous. Please read these operating instructions completely before setting up your fairy lights or lighting system. This product may only be operated with safety extra-low voltage (SELF) (protection class III). This product is not a toy! It must be kept out of the reach of children and must not be used as a toy. When connecting to the device terminals, please note the permitted cables and cross sections. Please note the technical data, especially the maximum current carrying capacity of the power path. Overloading can lead to the destruction of this product and/or a fire and must be avoided by carefully designing the light chain or lighting system and, if necessary, integrating the safety elements both in normal operation and in the event of a fault. Install and connect this product only when there is no voltage! Make sure the polarity is correct! For safety and approval reasons (CE), unauthorized conversion and/or modification of the device is not permitted. We assume no liability for property damage or personal injury caused by improper use or failure to observe the hazard warnings. In these cases, the warranty claim also expires! We assume no liability for consequential damage. Keep the usage information digitally or printed so that you can always access it. This product is only suitable for use in apartment-like environments. Protect this product from electrostatic discharge to avoid damage. Any use other than that described in this usage information is not intended and leads to exclusion of warranty and liability.
